ABB, 2CCS892001R0164 S802N-C16 High Performance MCB

Technical

Standards:

IEC/EN 60947-2

IEC/EN 60898-1

Tripping Characteristic:

C

Type of Residual Current:

Standard Version

Rated Operational Voltage:

acc. to IEC 60898-1 400 V AC

acc. to IEC 60947-2 690 V AC

Operational Voltage:

Maximum 230/400 V AC

Minimum 12 V AC

Rated Insulation Voltage (Ui):

acc. to IEC/EN 60664-1 690 V

Rated Impulse Withstand Voltage (Uimp):

8 kV

Input Voltage Type:

AC/DC

Rated Current (In):

16 A

Rated Short-Circuit Capacity:

(400 V AC) 20 kA

Rated Ultimate Short-Circuit Breaking Capacity (Icu):

(415 V AC) 36 kA

(440 V AC) 20 kA

(500 V AC) 10 kA

(690 V AC) 4.5 kA

(250 V DC) 20 kA

Rated Service Short-Circuit Breaking Capacity (Ics):

(415 V AC) 30 kA

(440 V AC) 15 kA

(500 V AC) 8 kA

(690 V AC) 3 kA

(250 V DC) 20 kA

Frequency (f):

50 ... 60 Hz

Rated Frequency (f):

50/60 Hz

Power Loss:

6.2 W

at Rated Operating Conditions per Pole 3.1 W

Contact Position Indication:

ON / OFF / TRIP

Energy Limiting Class:

3

Electrical Endurance:

10000 cycle

Mechanical Endurance:

10000 cycle

Number of Protected Poles:

2

Number of Poles:

2

Overvoltage Category:

IV

Tightening Torque:

3.5 N·m

31 in·lb

Release Type:

C

Actuator Marking:

I / O

Housing Material:

Insulation group I, RAL 7035

Mounting on DIN Rail:

TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715

TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715

Mounting Position:

Any

Recommended Screw Driver:

Pozidriv 2

Accessories Available:

Yes

Remarks:

Connection from top and bottom Connecting with CU only IP40 in enclosure with cover Cage terminal with captive screw

Connecting Capacity:

Flexible 0 … 50 mm²

Rigid 0 … 70 mm²

Terminal Type:

Screw Terminals

Material Compliance

RoHS Information:

9AKK107680A3903

2CCC005083D0202

RoHS Status:

Following EU Directive 2011/65/EU

RoHS Date:

20170426

Conflict Minerals Reporting Template (CMRT):

9AKK108468A3363

Environmental

Ambient Air Temperature:

Operation -25 ... +60 °C

Storage -40 ... +70 °C

Reference Ambient Air Temperature:

acc. to IEC60947-2 30 °C

acc. to EN60898-1 30 °C

Degree of Protection:

IP20

Pollution Degree:

3

Resistance to Vibrations:

1 mm 2 - 13.2 Hz

0.7g with Load 100% x Ie 13.2 - 100 Hz

Resistance to Shock acc. to IEC 60068-2-27:

5 g

30 ms

Environmental Information:

2CCY413207D0203

Dimensions

Width in Number of Modular Spacings:

3

Product Net Width:

54 mm

Product Net Height:

95 mm

Product Net Depth / Length:

82.5 mm

Product Net Weight:

490 g

Size:

2 modules

Built-In Depth (t2):

82.5 mm

Dimension Diagram:

2CCC413003C0201

Ordering

Package Level 1 Units:

box 1 piece

Package Level 1 Gross Weight:

510 g

Certificates and Declarations

CB Certificate:

2CCC413027D0201

CCC Certificate:

CQC2007010307228826

Declaration of Conformity - CE:

2CCC005083D0202

ESTI Certificate:

9AKK107680A0846

KC Certificate:

9AKK107680A0932

VDE Certificate:

2CCC413039D0601

Installation

Instructions and Manuals:

2CCC413016M0008

Popular Downloads

Data Sheet, Technical Information:

9AKK108468A9560

9AKK108468A9561

9AKK108468A9562

Classifications

ETIM 8:

EC000042 - Miniature circuit breaker (MCB)

ETIM 9:

EC000042 - Miniature circuit breaker (MCB)

WEEE Category:

5. Small Equipment (No External Dimension More Than 50 cm)

WEEE B2C / B2B:

Business To Business

CN8:

85362020

eClass:

V11.0 : 27141901

Object Classification Code:

F
