Festo, Pressure sensor SPAN-P10R-G18M-PNLK-PNVBA-L1 (8035533)

Technical Data

• Symbol00995685
• CertificationRCM compliance mark c UL us - Listed (OL)
• CE marking (see declaration of conformity)As per EU EMC directive As per EU RoHS directive
• UKCA marking (see declaration of conformity)To UK instructions for EMC To UK RoHS instructions
• Certificate issuing authorityUL E322346
• Note on materialsRoHS-compliant
• Measured variableRelative pressure
• Method of measurementPiezoresistive pressure sensor
• Pressure measuring range initial value0 MPa
• Pressure measuring range initial value0 bar
• Pressure measuring range initial value0 psi
• Pressure measuring range end value1 MPa
• Pressure measuring range end value10 bar
• Pressure measuring range end value145 psi
• Max. overload pressure15 bar
• Overload pressure1.5 MPa
• Overload pressure15 bar
• Overload pressure217.5 psi
• Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
• Information on operating and pilot mediaOperation with oil lubrication possible
• Temperature of medium0 °C ... 50 °C
• Ambient temperature0 °C ... 50 °C
• Accuracy in ± % FS1.5 %FS
• Repetition accuracy in ± %FS0.3 %FS
• Temperature co-efficient in ± %FS/K0.05 %FS/K
• Switching output2 x PNP or 2 x NPN switchable
• Switching functionWindow comparator Threshold value comparator Auto difference monitoring
• Switching element functionN/C contact/N/O contact switchable
• Max. output current100 mA
• Analog output0 - 10 V 4 - 20 mA 1 - 5 V
• Max. load resistance of current output500 Ohm
• Min. load resistance of voltage output20 kOhm
• Short-circuit protectionyes
• ProtocolIO-Link®
• IO-Link®, protocol versionDevice V 1.1
• IO-Link®, profileSmart sensor profile
• IO-Link®, function classesBinary data channel (BDC) Process data variable (PDV) Identification Diagnostics Teach channel
• IO-Link®, communication modeCOM2 (38,4 kBd)
• IO-Link®, SIO mode supportYes
• IO-Link®, port classA
• IO-Link®, process data width OUT0 Byte
• IO-Link®, process data width IN2 Byte
• IO-Link®, process data content IN14 bit PDV (pressure measurement) 2 bit BDC (pressure monitoring)
• IO-Link®, minimum cycle time3 ms
• IO-Link®, data memory required500 byte
• DC operating voltage range15 V ... 30 V
• Reverse polarity protectionfor all electrical connections
• Electrical connection 1, connection typePlug
• Electrical connection 1, connection technologyConnection diagram L1J
• Electrical connection 1, number of pins/wires4
• Electrical connection for input 1, connection pattern00995428
• Type of mountingFront panel mounting With thread With wall/surface bracket
• Mounting positionAny
• Pneumatic connectionExternal thread G1/8 Internal thread M5
• Product weight46 g
• Housing materialPA-reinforced
• Materials in contact with the mediaFPM High-alloy stainless steel
• Display typeIlluminated LCD
• Displayable unit(s)MPa bar inH2O inHg kPa kgf/cm² mbar mmHg psi
• Setting optionsIO-Link® Teach-in Via display and pushbuttons
• Protection against tamperingIO-Link® PIN code
• Setting range threshold value0 % ... 100 %
• Setting range hysteresis0 % ... 90 %
• Degree of protectionIP40
• Corrosion resistance class (CRC)2 - Moderate corrosion stress
• LABS (PWIS) conformityVDMA24364-B1/B2-L
• Suitability for the production of Li-ion batteriesMetals with more than 1% by mass of copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils
• Cleanroom classClass 4 according to ISO 14644-1
