Festo, Proximity sensor SMEO-1-B (30457)

Technical Data

• DesignBlock design
• Conforms to standardEN 60947-5-2
• Symbol00991624
• CE mark (see declaration of conformity)To EU EMC Directive To EU Low Voltage Directive In accordance with EU RoHS Directive
• CE marking (see declaration of conformity)To UK instructions for EMC To UK RoHS instructions To UK regulations for electrical equipment
• Note on materialsRoHS-compliant
• Measured variablePosition
• Measuring principleMagnetic reed
• Ambient temperature-20 °C ... 70 °C
• Repetition accuracy0.2 mm
• Switching outputContacting, bipolar
• Switching element functionN/O contact
• Switch-on time0.5 ms
• Switch-off time0.03 ms
• Max. switching frequency500 Hz
• Max. output current1000 mA
• Max. output current AC1000 mA
• Max. output current DC1000 mA
• Max. switching capacity AC40 VA
• Max. switching capacity DC40 W
• Voltage drop≤0 V
• Off-state current0 mA
• Short circuit current ratingno
• Overload protectionNot available
• Operational voltage range AC0 V ... 250 V
• Operational voltage range DC0 V ... 200 V
• Reverse polarity protectionno
• Electrical connection 1, connection typeCable
• Electrical connection 1, connector systemOpen end
• Electrical connection 1, number of connections/cores2
• Connection outlet orientationIn-line
• Cable length2.5 m
• Cable sheath colourgrey
• Material cable sheathPVC
• Type of mountingWith accessories
• Tightening torque2.9 Nm
• Mounting positionoptional
• Product weight100 g
• Housing colourBlack
• Material housingEpoxy resin PC PET Steel TPE-O Die-cast zinc
• Ambient temperature with moving cable-5 °C ... 70 °C
• Degree of protectionIP67
• Insulation voltage250 V
• Immunity to surge4 kV
• LABS (PWIS) conformityVDMA24364-B2-L
• Pollution degree3
